Inwertery Phoenix VE.Direct

Inwertery Phoenix VE.Direct

Phoenix 12/375 VE.Direct Phoenix 12/375 VE.Direct

VE.Direct communication port:

The VE.Direct port can be connected to:

  • A computer (VE.Direct to USB interface cable needed)
  • Apple and Android smartphones, tablets, macbooks and other devices (VE.Direct Bluetooth Smart dongle needed)

Fully configurable:

  • Low battery voltage alarm trip and reset levels
  • Low battery voltage cut-off and restart levels
  • Dynamic cut-off: load dependent cut-off level
  • Output voltage 210 - 245V
  • Frequency 50 Hz or 60 Hz
  • ECO mode on/off and ECO mode sense level

Monitoring:

  • In- and output voltage and current alarms

Proven reliability
The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature.

High start-up power
Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.

ECO mode
When in ECO mode, the inverter will switch to standby when the load decreases below a preset value. Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.

Remote on/off
A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector.

LED diagnosis
Please see manual for a description.

Available with different output sockets

Schuko UK AU/NZ EC-320

Phoenix Inverter
12V
24V
48V
12/250
24/250
48/250
12/375
24/375
48/375
12/500
24/500
48/500
Cont. power at 25°C 250VA 375VA 500VA
Cont. power at 25°C/40°C 200W/175W 300W/260W 400W/350W
Peak power 400W 700W 900W
Output AC voltage/ frequency (adjustable) 230VAC ±3%, 50Hz or 60Hz ±0,1%
Input voltage range 9,2V-17V / 18,4V-34V / 36,8V-62V
DC low shut down (adjustable) 9,3V / 18,6V / 37,2V
Dynamic cut-off, see
DC low restart and alarm (adjustable) 10,9V / 21,8V / 43,6V
Battery charged detect (adjustable) 14V / 28V / 56V
Max. efficiency 87% / 88% / 88% 89% / 89% / 90% 90% / 90% / 91%
Zero-load power 4,2W/ 5,2W / 7,9W 5,6W / 6,1W / 8,5W 6W / 6,5W / 9W
Default zero-load power in ECO mode (default rety interval: 2.5s ,adjustable) 0,8W / 1,3W / 2,5W 0,9W / 1,4W / 2,6W 1W / 1,5W / 3W
Protection Protection key: output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, DC ripple too high
Operating temperature range -40°C ÷ +65°C   (derate 1,25% per °C above 25°C)
Humidity (non-condesing) 95%
Material [&] Colour Steel chassis and plastic cober (blue Ral 5012)
Battery-connection Screw terminals
Maximum cable cross-section 10mm2 / AWG8
Standard AC outlets Schuko (CEE 7/4), IEC-320 (male plug icluded), UK (BS 1363), AU/NZ (AS/NZS 3112)
Protection category IP21
Weight 2,4kg 3kg 3,9kg
Dimensions 86/165/260mm 86/165/260mm 86/172/275mm
Normy EN/IEC60335-1, EN/IEC62109-1, EN55014-1, EN55014-2, IEC61000-6-1, IEC61000-6-3, 3004/104/EC, EN50498
