P600G - Low voltage limiter - 50802

The P600G is a gas discharge tube designed to equalize potentials on building installation components or technological assemblies that are not galvanically connected (in accordance with the ČSN EN 62305 Ed. 2 series of standards). It is primarily recommended for protecting insulated flanges and insulated threaded connections of cathodically protected industrial process piping components. If a potential difference exceeding 600 V occurs between these components, the tube tube will trip and temporarily conductively connect both components (the typical internal resistance of the P600G is 0.001-0.002 W). The P600G can be installed both indoors and outdoors, as well as in damp or underground locations. The functional component of the P600G is a special, gas-filled lightning arrester with a shortened response time of 20 ns, rated for a lightning current of 100 kA (10/350). The outer casing is made of light blue silicone rubber, which is hydrophobic and offers excellent resistance to weather conditions, pollution, and UV radiation. The mounting bracket, mounting screws, and nuts are made of stainless steel, suitable for connecting a 16-50 mm² Fe (Cu) cable. The product is supplied with an integrated bracket, allowing the P600G to be mounted directly to the protected metal structure (pole, wall, or flange).
