Slotted light barrier (infrared light) - PM type
  • Slotted light barrier (infrared light) - PM type

Photos are for informational purposes only. View product specification

Manufacturer: Vester

Slotted light barrier (infrared light) - PM type

Slotted light barrier (infrared light) - PM type
Specifications:
• Circuit: type PSL... -Laser chopped light trigger
  type PKL... -Laser chopped light trigger
• Wave length red light 650 nm
• Light beam diameter 0,2mm
• Laser capacity laser-class 2, < 1 mW
• Voltage 12...30V
• Current consumption max 60mA
• Operation static
• Output with LED: PNP
• Function bright-dark switch
• Output current 500mA,
• Repeatability < 0,02mm
• Frequency > 1kHz
• Operating temperature: 0...45°C
• EMC: IEC 801.... CE
• Type of protection IP 65
• Connection type: type PSL... -3-pole M8 socket
  type PKL... -cable 1,5m
• Fork depth: type PSL... - 8mm
  type PKL...- lOmm
Accuracy:
  type PSL... gap width A: 10 - 40 mm
  Element diameter: > 0,2 mm<
  type PKL... Gap width  20  30  50  80 mm
  Element diameter:      0,2 0,2   0,3 0,3 mm

Dimensions [mm]
PSL
PKL

TypeLight barrierDimensionsTerminal -3-pole M8 socket
AB
PSL-10-30/3-P 6532-00000-3002 10 30
PSL-20-30/3-P 6534-00000-3002 20 30
PSL-25-80/3-P 6560-00000-3002 25 80
PSL-30-30/3-P 6536-00000-3002 30 30
PSL-30-60/3-P 6555-00000-3002 30 60
PSL-40-40/3-P 6557-00000-3002 40 40
PSL-40-80/3-P 6559-00000-3002 40 80
PKL-20 6533-00000-3022 20 20
PKL-30 6536-00000-3022 30 30
PKL-50 6574-00000-3022 50 50
PKL-80 6576-00000-3022 80 50
