Slotted light barrier (infrared light) - PM type
  • Slotted light barrier (infrared light) - PM type

Photos are for informational purposes only. View product specification

Manufacturer: Vester

Slotted light barrier (infrared light) - PM type

Slotted light barrier (infrared light) - PM type
Specifications:
• Circuit: chopped light trigger
• Voltage: 12...30V
• Current consumption: max 60mA
• Operation: static
• Output with LED: PNP
• Function: bright-dark switch
• Output current: 500mA,
• Repeatability: < 0,02mm
• Frequency: > 1kHz
• Operating temperature: 0...60°C
• EMC: IEC 801.... CE
• Type of protection: IP 65

Accuracy:
• type PKI-.../K gap width A: 10- 20mm
  element diameter:     0,6-0,7mm
• type PKI-... gap width A: 20- 30- 50- 80mm
  element diameter:     0,7- 0,8-0,9- 1,2mm


Dimensions [mm]

PKI-...-/K

PKI-...


TypeLight barrierDimensionsTerminal 3-pole M8 socket
AB
PKI-10/K 6331-00000-0022 10 13
PKI-20/K 6333-00001-0022 20 13
PKI-20 6333-00000-0022 20 20
PKI-30 6336-00000-0022 30 30
PKI-50 6374-00000-0022 50 50
PKI-80 6376-00000-0022 80 50
