Three phase bridge rectifiers
  • Three phase bridge rectifiers

Photos are for informational purposes only. View product specification

Manufacturer: Diotec

Three phase bridge rectifiers

DIOTEC BRIDGE RECTIFIERS

THREE PHASE BRIDGE RECTIFIERS



Table. Electrical Data

Casing Type40 x 20 x 1028.5 x 28.5 x 10
One phase bridgesVoltage
V RRM
[V]
Current6 [A]15 [A]25 [A]15 [A]25 [A]35 [A]
Standard 50 DBI 6-005 DBI 15-005 DBI 25-005 DB 15-005 DB 25-005 DB 35-005
100 DBI 6-01 DBI 15-01 DBI 25-01 DB 15-01 DB 25-01 DB 35-01
200 DBI 6-02 DBI 15-02 DBI 25-02 DB 15-02 DB 25-02 DB 35-02
400 DBI 6-04 DBI 15-04 DBI 25-04 DB 15-04 DB 25-04 DB 35-04
600 DBI 6-06 DBI 15-06 DBI 25-06 DB 15-06 DB 25-06 DB 35-06
800 DBI 6-08 DBI 15-08 DBI 25-08 DB 15-08 DB 25-08 DB 35-08
1000 DBI 6-10 DBI 15-10 DBI 25-10 DB 15-10 DB 25-10 DB 35-10
1200 DBI 6-12 DBI 15-12 DBI 25-12 DB 15-12 DB 25-12 DB 35-12
1400 DBI 6-14 DBI 15-14 DBI 25-14 DB 15-14 DB 25-14 DB 35-14
1600 DBI 6-16 DBI 15-16 DBI 25-16 DB 15-16 DB 25-16 DB 35-16
