Traction Fuses Series 170M, 2000VDC, from 20A to 600A
  • Traction Fuses Series 170M, 2000VDC, from 20A to 600A

Photos are for informational purposes only. View product specification

Manufacturer: EATON Bussmann

Traction Fuses Series 170M, 2000VDC, from 20A to 600A

  • Rated current: 20-600A160-400A500-600A
  • Rated voltage: 2000VDC
  • Breaking capacity: 100kA at 2000Vdc, L / R < 15ms100kA at 1500Vdc, L / R

CodeRated voltage [Vdc]Rated current [A]I2t
[A2s]
Watts Loss
[W]
Housing
Pre-ArcingTotal at 2000V0,8 lnln

170M2046

2000 20 85 240 9 12 Drawing 1

170M2047

25 130 390 9 16

170M2048

32 220 645 11 18

170M2049

40 390 1140 12 20

170M2050

50 610 1780 17 33

170M2051

63 1030 3000 20 39

170M2052

80 1555 4550 28 53

170M2053

100 2680 7840 33 63

170M2054

125 4110 12,02 42 79

170M2055

160 6620 19,36 45 87

170M2056

200 10,72 31,36 50 95

170M2057

215 21,87 64 51 97

170M2039

2000 160 7875 75,96 68 91 Drawing 2

170M2040

200 12,3 118,67 85 113

170M2041

250 21,87 211 100 133

170M2042

315 38,88 375,11 119 158

170M2043

400 65,71 633,965 148 176

170M2044

2000 500 105,851 163,01 109 230 Drawing 3

170M2045

600 188,179 289,796 153 305
Dimensions [mm]
Drawing 1
Bezpieczniki trakcyjne sererii 170M, 2000Vdc, od 20A do 600A wymiar
Drawing 2
Bezpieczniki trakcyjne sererii 170M, 2000Vdc, od 20A do 600A wymiar

Drawing 3

Bezpieczniki trakcyjne sererii 170M, 2000Vdc, od 20A do 600A wymair
