Kontaktoriai 110-420 EI
  • Kontaktoriai 110-420 EI

Nuotraukos yra skirtos tik informaciniams tikslams. Peržiūrėkite produkto specifikaciją

Gamintojas: Danfoss

Kontaktoriai 110-420 EI

Series of types of AC contactors in the range of 55 - 220 kW. For models marked as EI it is also possible to control directly from the PLC, with a build in interface, with independent coil supply with AC voltage. Build in interface optimises coil power consumption and provides operation without sounds. Completely tight construction allows for operation in hard conditions. It is possible to manually turn on contactor.The additional contacts block NO + 1NC is mounted in standard, but there is possibility to make extension of three the same blocks.It is recommended to use anty shock shields on the cables tips.



Electrical parameters -AC coil
TypeUe 230V kWUe 400V kWle
(AC - 3)
[A]
Ith 40°C
(AC - 1)
[A]
Ith 60°C
(AC - 1)
[A]
Main contactAdditional contactCatalogue number
Cl 110 32 55 110 160 135 3 1NO + 1NC 037H3081XX
Cl 141 45 75 140 250 210 3 1NO + 1NC 037H3339XX
Cl 180 55 90 180 250 210 3 1NO + 1NC 037H3082XX
Cl 210EI 63 110 210 350 300 3 1NO + 1NC 037H3259XX
Cl 250EI 80 132 250 350 300 3 1NO + 1NC 037H3267XX
CI 300EI 90 160 300 450 380 3 1NO + 1NC 037H3269XX
CI 420EI 132 220 420 500 425 3 1NO + 1NC 037H3279XX



Coil for CI110 -CI180

Control voltageSymbol XXCatalogue number
110 V 50Hz 22 037H3261
220-230 V 50Hz 31 037H3262
380-400V 50Hz 37 037H3264


Coil for CI210EI - CI300EL

Control voltageSymbol XXCatalogue number
110-130 V
50/60HZ
23 037H3413
208-277 V
50/60Hz
32 037H3415
380-500 V
50/60Hz
39 037H3417


Coil for CI420EI

VoltageSymbolNumber
110-130 V
50/60HZ
23 037H3421
208-277 V 50/60HZ 32 037H3423
380-500 V 50/60HZ 39 037H3425




Accessories



Functionle
[A]
Ith 60°C
[A]
Ue
[V]
Catalogue numberType
1 NO + 1 NC 5.5 16 690 037H3348 CBC - 11



Dimensions



CI 110 do CI 180 + TI 180 E
CI 210 EI do CI 420 EI + TI 630 E
