DSP1250 MARECHAL Single-Pole Connector (1250 A, 1000 V) – Extreme Performance

DSP1250 single-pole connectors are a safe, reliable, and highly efficient solution designed for applications requiring very high continuous electrical power, up to 1250 A and 1000 V. These connectors are characterized by their high capacity to absorb frequent overloads, which is crucial in sectors such as energy, heavy industry, and emergency power systems. The IK10-rated metal housing guarantees maximum safety and durability.

Key Features and Design of the DSP1250 Connector

The DSP1250 series is designed for the most demanding high-current applications, providing both the performance and protective features necessary for safe operation.

• Electrical Parameters: 1250 A, 1000 V (data from the product specifications).
• Electromechanical Locking System.
• Automatic IP rating: IP66/IP67 (protection against powerful water jets and immersion).
• Metal casing, highest mechanical resistance IK10.
• Operating temperature: from -40 °C to +60 °C.

Compliance with standards and regulations

DSP1250 connectors meet key European directives, confirming their compliance with safety, environmental protection, and quality requirements.

• Compliance with the European Low Voltage Directive (LVD) and RoHS (CE marking) and the European REACH regulation.
