Input types: thermocouple - K, E, J, T, B, R, S, N
Types of outputs: current 4… 20mA
Possibility to make the range of inputs / outputs on special order.
| Wire connection | M3 screw terminals |
|---|---|
| Separation | Input / Output / Power |
| Dielectric Strength | For DC power: 2000V AC |
| Range selection | Input - 100Ω - 10kΩ, output 4… 20mA |
| Double Output | None |
| Power | DC |
| Working Temperature | - 40 to + 80 ° C |
| Montage | On a DIN rail |
| Dimensions | 25x41x97mm |
