| Parameter name | Parameter value | |
|---|---|---|
| Power supply | 4× AAA alkaline battery 1.5 V or NiMH accumulator 1.2 V | |
| Measuring range (test of SPDs) | 40 V ÷ 1 050 V | |
| Resolution (test of SPDs) | 1 V | |
| Reference error (test of SPDs) | ± (2 % z R + 2 D)* | |
| Measuring principle (test of SPDs) | Increasing DC voltage and simultaneously measures the 1 mA current through the SPD | |
| Measuring range (insulation resistance) | 0.100 MΩ ÷ 9.999 GΩ (U = 50 V ÷ 1,000 V) | |
| Nominal test current max (insulation resistance) | 1 mA | |
| Automatic discharge of tested object (insulation resistance) | yes | |
| Measuring range (voltage TRMS) | 0 V ÷ 600 V DC / AC (45 Hz ÷ 65 Hz) | |
| Resolution (voltage TRMS) | 1 V | |
| Reference error (voltage TRMS) | ± (2 % z R + 2 D)* | |
| Overvoltage category | CAT III / 300 V or CAT II / 600 V | |
| Display | High contrast bright multicolour graphic OLED | |
| Dimensions | 260 x 70 x 40 mm | |
| Weight (including batteries and measuring tip) | 0.36 kg | |
| ETIM Class | EC002495 | |
| Remark | * R = reading, D = digit | |
| Customs tariff number | 90303100 | |
| EAN | 8595090500100 |
