M2LR - перетворювач температури з RTD Input - Настроюваний
M2LR - перетворювач температури з RTD Input - Настроюваний

Zdjęcia mają charakter wyłacznie informacyjny. Zobacz specyfikację produktu

please use latin characters

Producent: M-SYSTEM

M2LR - перетворювач температури з RTD Input - Настроюваний

  • M2LR

M2LR is a temperature converter with RTD input. It has an OEL display. Ranges of inputs and outputs calibrated by a PC or by buttons on the front of the housing.


Features

  • Mounting socket for each model - allows easy assembly / disassembly and quick converting converters without the need to interfere with the wiring
  • Programmable by means of a PC and buttons on the front of the housing
  • AC power
  • LED power indicator
  • Installation on DIN rail
  • 2000V AC insulation

Input types: RTD - JPt 100 (JIS'89), Pt 100 (JIS'89), Pt 100 (JIS'97, IEC), Pt 50Ω (JIS'81), Ni 508.4Ω, Pt 1000, Ni 100, Cu 10 @ 25 ° C
Types of outputs: current or voltage with different ranges
Range can be made special order entries / exits.


< / tr>
Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric strength DC: 2000V AC
AC: 1500V AC
Ranges selection Configurable with PC and front buttons
Dual output None
Power AC
Working Temperature - 5 to +55 ° C
Mounting DIN rail
Dimensions 23x76x124mm
Mniej
Czytaj więcej

Wyślij zapytanie ofertowe

Jesteś zainteresowany tym produktem? Potrzebujesz dodatkowych informacji lub indywidualnej wyceny?

Skontakuj się z nami
Запитайте про продукт close
Дякуємо за надіслане повідомлення. Ми відповімо якомога швидше.
Запитайте про продукт close
Огляд
Надіслати запит

Add to wishlist

Musisz być zalogowany/a

M2LR is a temperature converter with RTD input. It has an OEL display. Ranges of inputs and outputs calibrated by a PC or by buttons on the front of the housing.


Features

  • Mounting socket for each model - allows easy assembly / disassembly and quick converting converters without the need to interfere with the wiring
  • Programmable by means of a PC and buttons on the front of the housing
  • AC power
  • LED power indicator
  • Installation on DIN rail
  • 2000V AC insulation

Input types: RTD - JPt 100 (JIS'89), Pt 100 (JIS'89), Pt 100 (JIS'97, IEC), Pt 50Ω (JIS'81), Ni 508.4Ω, Pt 1000, Ni 100, Cu 10 @ 25 ° C
Types of outputs: current or voltage with different ranges
Range can be made special order entries / exits.


< / tr>
Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric strength DC: 2000V AC
AC: 1500V AC
Ranges selection Configurable with PC and front buttons
Dual output None
Power AC
Working Temperature - 5 to +55 ° C
Mounting DIN rail
Dimensions 23x76x124mm
