Nuotraukos yra skirtos tik informaciniams tikslams. Peržiūrėkite produkto specifikaciją

please use latin characters

Gamintojas: DACPOL

Tiristoriaus modulis – M2T..P

One element power thyristor block with radiator RY.
Properties:
• One element power diode block with both side cooling– RY
• Natural cooling
Typical applications:
• rectifiers, converters, supplies
• DC power regulator
• power contactors
• soft-starts

Options:
• Standard – Diagram. 1
• with current buses – Diagram. 2
• With blacken radiator
• Thermal protection
• RC circuit
• fuse
• forced cooling - drawing 3

Power block selection:
• There are different semiconductors used, depending on the load. Used semiconductor size is given in the Table 1.
Drawing1
Drawing2
Drawing3



Operation conditions:
One element power blocks are used in power electronic systems.
• Ambient air temperature-100 C - +400 C
• Atmospheric pressure  860hPa - 1060hPa
• Humidity less then 80% @ temperature 400 C
• Cooling air without aggressive factors.

Scheme



Table 1 Power blocks parameters


Module type Mean current IF(AV) [A] Blocking voltage U RRM
    [V]		 Over current voltage
I FSM
[A]		 Dimensions
[mm]		 Block weight
[kg]
M2T7P 450…650 400…2400 7000…10000 3,1
M2T8P 630…1000 400…8500 10000…24000 3,3
M2T9P 1000…2000 400…7500 20000…42000 7,9
M2T11P 1000…3200 400…6000 27000…65000 12


Basic factor, which has influence on power blocks quality is their proper assembly and correct semiconductor selection.
Power block scheme M2T...P
