Technical data
 Operating temperature range: -25oC ÷70oC
 Tolerance: ±10%
| Type | UN [VDC] | Capacitance [µF] | Us [V] | Imax A | dv/dt V/us | L [nH] | Rs [mΩ] |
|---|---|---|---|---|---|---|---|
| LNK-P8X-1500-70 | 700 | 1500 | 1400 | 180 | 10 | 30 | 0.22 |
| LNK-P8X-850-90 | 900 | 850 | 1800 | 155 | 12 | 30 | 0.27 |
| LNK-P8X-700-100 | 1000 | 700 | 2000 | 150 | 13 | 30 | 0.30 |
| LNK-P8X-600-110 | 1100 | 600 | 2200 | 145 | 14 | 30 | 0.31 |
| LNK-P8X-430-125 | 1250 | 430 | 2500 | 140 | 17 | 30 | 0.36 |
| LNK-P8X-330-145 | 1450 | 330 | 2900 | 130 | 19 | 30 | 0.40 |
| LNK-P8X-200-180 | 1800 | 200 | 3600 | 120 | 24 | 30 | 0.51 |

¿Estás interesado en este producto? ¿Necesita información adicional o precios individuales?
Usted debe estar conectado
Technical data
 Operating temperature range: -25oC ÷70oC
 Tolerance: ±10%
| Type | UN [VDC] | Capacitance [µF] | Us [V] | Imax A | dv/dt V/us | L [nH] | Rs [mΩ] |
|---|---|---|---|---|---|---|---|
| LNK-P8X-1500-70 | 700 | 1500 | 1400 | 180 | 10 | 30 | 0.22 |
| LNK-P8X-850-90 | 900 | 850 | 1800 | 155 | 12 | 30 | 0.27 |
| LNK-P8X-700-100 | 1000 | 700 | 2000 | 150 | 13 | 30 | 0.30 |
| LNK-P8X-600-110 | 1100 | 600 | 2200 | 145 | 14 | 30 | 0.31 |
| LNK-P8X-430-125 | 1250 | 430 | 2500 | 140 | 17 | 30 | 0.36 |
| LNK-P8X-330-145 | 1450 | 330 | 2900 | 130 | 19 | 30 | 0.40 |
| LNK-P8X-200-180 | 1800 | 200 | 3600 | 120 | 24 | 30 | 0.51 |
