| Supply voltage | 10-30V DC |
| Supply voltage ripple | ≤ 3,5V |
| Load current | 150mA |
| Current consumption | < 20mA |
| Residual voltage | < 2,5V DC |
| Residual current | <10μA |
| Output resistance | Open collector |
| Light source | LED IR |
| Output | NPN/PNP NO and NC |
| Switching frequency (impulse/break 1:1)          150Hz | |
| Optic circuit | Glass lens |
| Operation temperature | -10°C - +55°C |
| Protection level | IP 65 |
| Casing | Nickled brass |
| Connection method | PCW cable 2m., 4x0,14mm2 |
| Metal casing | M18x1 | M18x1 | M18x1 | M18x1 | M30x1,5 | ||||||
| Sensitivity zone | 100 | 200 | 400 | 1000 | 2000 | ||||||
|  |  |  |  |  |  | ||||||
| Operation area | 0-100mm | 0-200mm | 0-400mm | 0-1000mm | 0-2000mm | ||||||
| Object dimensions | white cardboard 200X200mm | white cardboard 200X200mm | white cardboard 200X200mm | white cardboard 200X200mm | |||||||
| Sensitivity regulation | potentiometer | potentiometer | potentiometer | potentiometer | potentiometer | ||||||
| Sensor marking | NC NO | TOO18-100R TOO18-100Z | TOO18-200R TOO18-200Z | TOO18-400R TOO18-400Z | TOO18-1000R TOO18-1000Z | TOO30-2000R TOO30-2000Z | |||||
|  |  |
| Operation area | M18x1 | M18x1 | M18x1 | M18x1 | M30x1,5 | ||||||||||||||||||||
| Sensitivity area | 100 | 200 | 400 | 1000 | 2000 | ||||||||||||||||||||
|  |  |  |  |  |  | ||||||||||||||||||||
| Operation zone | 0-100mm | 0-200mm | 0-400mm | 0-1000mm | 0-2000mm | ||||||||||||||||||||
| Object dimensions | white cardboard 200X200mm | white cardboard 200X200mm | white cardboard 200X200mm | white cardboard 200X200mm | |||||||||||||||||||||
| Sensitivity control | - | - | - | - | potentiometer | ||||||||||||||||||||
| Sensor marking | NC NO | TOO18-100RK TOO18-100ZK | TOO18-200RK TOO18-200ZK | TOO18-400RK TOO18-400ZK | TOO18-1000RK TOO18-1000ZK | TOO30-2000RK TOO30-2000ZK | |||||||||||||||||||
| M12-connector in sensor |  |  | |||||||||||
|  |
 | ||||||||||||
