| Features:
 |
| Item | GQ-001 | GQ-002 | GQ-004 | GQ-006 | GQ-008 |
|---|---|---|---|---|---|
| Output torque | 15Nm | 20Nm | 40Nm | 60Nm | 80Nm |
| Operating time | 3s | 4s | 7s | 15/17s | 15/17s |
| Supplying power | 2 or 24VAC/DC, 95~245VAC | 24VAC or DC, 110 or 220VAC | |||
| Limit switches | 2 Limit switch for operation, 2 additional limit switch for dry contact | ||||
| Manual operation | Manual lever | ||||
| Enclosure | IP67 | ||||
| Mounting base | F03/04/05 (ISO5211) | F05/07 (ISO5211) | |||
| Bottom bore | 11 X 11 | 14 X 14 | 14 X 14 | 14 X 14 | 14 X 14 |
| Conduit Entries | PF1/2x 1EA | PF1/2x 2EA | |||
| Weight | 1.2Kg | 3.5Kg | |||
