MOSFET-Module von MITSUBISHI
  • MOSFET-Module von MITSUBISHI

Fotos dienen nur zu Informationszwecken.

please use latin characters

Hersteller: Mitsubishi

MOSFET-Module von MITSUBISHI

Electrical data

  • Low voltages VDS(ON) and VSD
  • MOSFET structure in newest channel technology 0,35 µm
  • operation without snubber circuit
  • avalanche during turning off and reverse recovery time
  • output terminal compatible with typical connectors
  • include NTC thermistor
  • high reliability

Electrical data

Type Current
[A]
Voltage
[V]
RDS (on) (mΩ) @Tch=25°CTyp.
FM200TU-07A 100 75 2.0
FM200TU- 2A 100 3.0
FM200TU- 3A 150 8.0
FM400TU-07A 200 75 1.0
FM400TU- 2A 100 1.5
FM400TU- 3A 150 4.0
FM600TU-07A 300 75 0.67
FM600TU- 2A 100 1.0
FM600TU- 3A 150 2.67
