W2TS - Temperaturwandler mit einem Thermoelementeingang mit einem doppelten Ausgang
W2TS - Temperaturwandler mit einem Thermoelementeingang mit einem doppelten Ausgang

Fotos dienen nur zu Informationszwecken.

please use latin characters

Hersteller: M-SYSTEM

W2TS - Temperaturwandler mit einem Thermoelementeingang mit einem doppelten Ausgang

  • W2TS

W2TS is a temperature converter with thermocouple input with two outputs.


Features

  • AC / DC power
  • LED power indicator < / li>
  • Provides standard analog output
  • Dual output
  • DIN rail mounting
  • High accuracy
  • Type available with fast response time
  • 2000V AC insulation

Input types: Thermocouple - K, E, J, T, B, R, S, N
Types of outputs: current or voltage with different ranges
Possibility to make a range of inputs / outputs on a special order.


< / table>

Senden Sie eine Anfrage

Interessieren Sie sich für dieses Produkt? Benötigen Sie zusätzliche Informationen oder individuelle Preise?

Kontaktiere uns
FRAGEN SIE NACH DEM PRODUKT close
Vielen Dank für die Zusendung Ihrer Nachricht. Wir werden so schnell wie möglich antworten.
FRAGEN SIE NACH DEM PRODUKT close
Durchsuche

Zur Wunschliste hinzufügen

Sie müssen eingeloggt sein

W2TS is a temperature converter with thermocouple input with two outputs.


Features

  • AC / DC power
  • LED power indicator < / li>
  • Provides standard analog output
  • Dual output
  • DIN rail mounting
  • High accuracy
  • Type available with fast response time
  • 2000V AC insulation

Input types: Thermocouple - K, E, J, T, B, R, S, N
Types of outputs: current or voltage with different ranges
Possibility to make a range of inputs / outputs on a special order.


Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric Strength DC: 2000V AC
AC: 1500V AC
Ranges selection To be set when ordering
Double exit Yes
Power AC / DC
Operating Temperature - 5 to + 55 ° C < / td>
Mounting DIN rail
Dimensions 29.5x88.5x124mm
< / table>
Kommentare (0)
Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric Strength DC: 2000V AC
AC: 1500V AC
Ranges selection To be set when ordering
Double exit Yes
Power AC / DC
Operating Temperature - 5 to + 55 ° C < / td>
Mounting DIN rail
Dimensions 29.5x88.5x124mm
