Manufacturer: FANDIS

A08A23HWSF00 AC axial fan 230V 14W

  • A08A23HWSF00
  • Air flow direction Exhaust through brackets
  • Dimensions 80 x 80 x 25 mm
  • Rated voltage 230
  • Housing material Odlew aluminium
  • Protection rating IP44
  • Frequency 50
  • Input power 16
  • Speed 2600
  • Current draw 0,08
  • Air flow 32
  • Certificate CE; UR; UKCA
  • Mounting method screws
  • Static Pressure 35
  • Noise Level 32
  • Fan type AC axial
  • Voltage range 207-253
  • Type of voltage AC
  • Motor protection Impedance protection
  • Insulation class B
  • Motor bearing Plain bearing
  • Protection class I
  • Electrical hookup Wires
  • Storage temperature -40÷80 °C
  • Working temperature -40÷70 °C
