Fast thyristor/ fast thyristor
  • Fast thyristor/ fast thyristor

Photos are for informational purposes only. View product specification

Fast thyristor/ fast thyristor

VISHAY (IR) ELECTRO INSULATED MODULES


THYRISTOR/THYRISTOR

Table. Electrical Data


Module TypeIT(AV)
[A]
UDRM
[V]
ITSM
[A]
l2t
[A2s]
I GT
[mA]
du/dt
[V/µs]
Rthjc
[°C/W]
Rthcs
[°C/W]
Screw Torque
[Nm]
Casing
IRKT26/.. 27 400-1600 400 800 150 500 0,31 0,1 5 ADD-A-Pak
IRKT41/.. 45 400-1600 850 3610 150 500 0,23 0,1 5
IRKT56/.. 60 400-1600 1310 8500 150 500 0,2 0,1 5
IRKT71/.. 75 400-1600 1665 13860 150 500 0,165 0,1 5
IRKT91/.. 95 400-1600 1785 15910 150 500 0,135 0,1 5
IRKT105/.. 105 400-1600 1785 15910 150 500 0,135 0,1 5
IRKT136 135 400-1600 3200 51500 200 500 0,2 0,05 4-6 INT-A-Pak
IRKT142-.. 140 400-2000 4750 113000 200 500 0,17 0,05 4-6
IRKT162-.. 160 400-1600 5100 131000 200 500 0,17 0,05 4-6
IRKT170-.. 170 400-1600 5100 131000 200 500 0,17 0,02 4-6 MAGN-A-Pak
IRKT230-.. 230 400-2000 7500 280000 200 500 0,125 0,02 4-6
IRKT250-.. 250 400-1600 8500 361000 200 500 0,125 0,02 4-6
IRKT430-.. 430 800-2000 15700 1232000 200 1000 0,065 0,02 6-8 SUPER MAGN-A-Pak
IRKT500-.. 500 800-1600 17800 1591000 200 1000 0,065 0,02 6-8
