Parameter name | Parameter value | |
---|---|---|
Type of SPD | T1 | |
Maximum operating voltage | Uc | 275.00 V AC |
Maximum operating voltage | Uc | 350.00 V DC |
Short-circuit current rating | ISCCR | 50.0 kA |
Lightning impulse current (10/350 µs) | Iimp | 12.50 kA |
Nominal discharge current (8/20 µs) | In | 30.00 kA |
Maximum discharge current (8/20 µs) | Imax | 60.00 kA |
Voltage protection level | Up | 1.50 kV |
Response time | ta | 25 ns |
Fault indication | red indication field | |
ETIM Class | EC000941 | |
Customs tariff number | 85363090 | |
EAN | 8595090534310 |
