Air conditioners - SLIM type
  • Air conditioners - SLIM type

Photos are for informational purposes only. View product specification

Manufacturer: SEIFERT mtm SYSTEM

Air conditioners - SLIM type

A B C D E F G H
TypeCooling power
[W]
l35l35*
Dimensions
[mm]
Nominal current and voltage
[A/V]
Air flow
conditioner/cabinet
[m3/h]
Weight
[Kg]
KG-4270 600 810x395x135 2.8/230 360/180 35,0 A
KG-4270 120 600 810x395x135 7/120 360/180 32,0 A
KG-4270 400 600 810x395x135 1.6/400 360/180 35,0 A
KG-4271 820 980x395x135 2.8/230 360/180 39,0 B
KG-4271 120 820 980x395x135 7/120 360/180 36,0 B
KG-4271 400 820 980x395x135 1.6/400 360/180 39,0 B
KG-4272 1100 1250x395x135 3.4/230 450/250 42,0 C
KG^272 120 1100 1250x395x135 8/120 450/250 42,0 C
KG-4272 400 1100 1250x395x135 1.8/400 450/250 42,0 C
KG-4274 1500 1550x395x135 4/230 430/250 50,0 D
KG-4274 400 1500 1550x395x135 1,8/400 430/250 50,0 D
KG-4280 400 2000 1580x395x135 400 575/580 67,0 E
KG-8277 2600 158x395x290 2/400 670/685 70 E
KG-4290 1100 1200(1250)x395(445)x83.5(135) 2.8/230 450/250 45,0 G
KG-4290 120 1100 1200(1250)x395(445)x83.5(135) 7/120 450/250 45,0 G
KG-4290 400 1100 1200(1250)x395(445)x83.5(135) 1.6/400 450/250 45,0 G
KG-4295 1400 1500(1550)x395(445)x83.5(135) 3.8/230 430/250 52,0 H
KG-4295 120 1400 1500(1550)x395(445)x83.5(135) 8/120 430/250 52,0 H
KG-4295 400 1400 1500(1550)x395(445)x83.5(135) 1.3/400 430/250 52,0 H

Air conditioners with filter assembled on the cabinet roof

A B

VersionTypeCooling power
[W]
L35L35*
Dimensions
[mm]
Nominal current and voltage
[A/V]
Air flow
conditioner/cabinet
[m3h]
Weight
[Kg]
Roof without filter KG-4555 1100 400x600x400 4.0/230 720/360 55,0 A
KG-4555 120 1100 400x600x400 8.0/120 720/360 55,0 A
KG-4555 400 1100 400x600x400 2.3/400 720/360 55,0 A
Roof without filter KG-4515 1500 410x600x400 5.3/230 860/540 58,0 B
KG-4515 400 1500 410x600x400 3.0/400 860/540 58,0 B
Roof without filter KG-4520 2000 410x600x400 7.0/230 750/540 63,0 B
KG-4520 2000 410x600x400 3.7/120 750/540 63,0 B
