Manufacturer: FANDIS

D04E05HWBT00 DC axial fan 24V 2.16W

  • D04E05HWBT00
  • Air flow direction Exhaust through brackets
  • Dimensions 40 x 40 x 10 mm
  • Rated voltage 24
  • Housing material Plastik UL94-V0
  • Protection rating IP20
  • Input power 2,16
  • Speed 6000
  • Current draw 0,09
  • Air flow 10
  • Certificate CE; cURus; UKCA
  • Mounting method screws
  • Static Pressure 25
  • Noise Level 30.5
  • Voltage Input Min (V) 17
  • Fan type DC axial
  • Voltage range 21,6-26,4
  • Type of voltage DC
  • Motor protection Electronically secured
  • Insulation class A
  • Motor bearing Ball bearing
  • Electrical hookup Wires
  • Storage temperature -40÷70 °C
  • Working temperature -10÷70 °C
