Manufacturer: STEGO

Electronic hygrostat - EFR 012

- Humidity set up
- Optic operation indicator (LED)
- High contact current
- For DIN bus
- Temperature compensated

Switch over difference
5 % humidity(± 1 % tolerance) @ 25 °C i 50%
humidity
Reaction time
ok.5s
Contact type
Switch over
Lifetime
> 50.000 cycles
Max switch over current
AC 240V,8 (1,6)A
AC120V,8(1,6)A
DC24V,4A
Operation indicator
LED
Terminals
5 pole 2,5 mm2
Mounting
For DIN 35 mm bus, EN 60715
Casing
plastic  UL94V-0, light grey
Dimensions
64,5x42 x38mm
Weight
ok. 70 g
Assembly
Vertical
Operation temperature
0 do +60 °C / -20 do +70 °C
Max storage humidity
90 %
IP
IP20


Article number Operation temperature Range Certificates
01245.0-00  AC 230 V 50/60 Hz 40 do 90 % humidity VDE; (UL )
01246.0-00 AC 230 V 50/60 Hz 65 % humidity default VDE; (UL )
01245.9-00 AC 120 V 50/60 Hz 40 do 90 % humidity UL
01246.9-00 AC 120 V 50/60 Hz 65 % humidity default UL
