Manufacturer: Eaton / CEAG

XB4 LD1511B14 traffic light

  • LD1511B14

XB4 traffic light

  • Zones: 1, 2, 21, 22
  • Certificates: ATEX, IECEx, cULus, TR CU, CCOE
  • ATEX/IEC: Ex II 2GD, Ex d IIC T4/T5/T6 Gb; Ex tb IIIC T135°C/T100°C/T85°C Db; Ex II 2GD, Ex de IIC; Ex tD A21 T4/T5
  • UL/NEC: Class I, Div. 1, Groups C, D; Class I, Zone 1, Groups IIB & IIA
  • Temp. Operating Temperature: -55°C to +70°C
  • Protection Rating: IP66, IP67; NEMA 4X, 6
  • Housing: Stainless Steel or Steel
  • Entry: 4* × M20, M25, ½″ NPT or ¾″ NPT
  • Weight: Steel 6.6–7.6 kg; Stainless Steel 15–16 kg
  • Power Supply: 24–110 V DC, 110–254 V AC
  • Light Source: Xenon Bulb, 21 J

* applies to selected versions.
