Manufacturer: ZIEHL

STW161M - Bus Module for Slider - S225543

  • S225543
  • Product Type Motor IP00, electronics IP20 / depending on mounting and position
  • Supply voltage DC 24 V
  • Execution Die-cast aluminum
  • Certificate IP 30 (IP 44, with bracket and cover)
  • Output function Outputs/Relays
  • Measured value PA material reinforced with glass fiber.

Bus module for controlling sliders in extraction systems

STW161M and STW168M bus modules control gate valves in extraction systems in conjunction with STW164IP control units. The wiring effort is dramatically reduced by the bus technology.

Application:

Control of extraction systems in the wood and plastics processing industry in accordance with the Technical Rules for Hazardous Substances TRGS 553. The central automatic start-up switches the extraction system on as soon as a machine is put into operation. The shut-off valves in the extraction ducts of the individual machines are controlled via STW161M bus modules. DC 24 V is available as a signal. If required, the bus modules can also monitor the function of the shut-off valves (input for end position reached) and record the operating status of the extracted machine (on/off) via STWA1 current transformers or potential-free contacts and report this to the central control system.
