Fast diode
  • Fast diode

Photos are for informational purposes only. View product specification

Manufacturer: Vishay

Fast diode

Module typeIF(AV>
[A]
URRM
[V]
IFSM
[A]
I2t
[A2s]
trr
[MS]
Rthjc
[°C/W]
R thcs
[°C/W]
Screw torque
[Nm]
Casing
T40HFL...S.. 40 100-1000 475 1130 0,2-1 0,85 0,02 1,3 T-MODULE
T70HFL...S.. 70 100-1000 830 3460 0,2-1 0,53 0,02 1,3
T85HFL...S.. 85 100-1000 1300 8550 0,2-1 0,46 0,02 1,3
IRKEL240-..S.. 240 400-2500 7500 280000 1-2 0,125 0,02 4-6 MAGN-A-Pak
  250 400-2500 8000 322000 3 0,125 0,02 4-6
