Manufacturer: Victron energy
Phoenix ve.direct 250VA-500VA inverters
Inwertery Phoenix VE.Direct
|Phoenix 12/375 VE.Direct||Phoenix 12/375 VE.Direct|
VE.Direct communication port:
The VE.Direct port can be connected to:
- A computer (VE.Direct to USB interface cable needed)
- Apple and Android smartphones, tablets, macbooks and other devices (VE.Direct Bluetooth Smart dongle needed)
- Low battery voltage alarm trip and reset levels
- Low battery voltage cut-off and restart levels
- Dynamic cut-off: load dependent cut-off level
- Output voltage 210 - 245V
- Frequency 50 Hz or 60 Hz
- ECO mode on/off and ECO mode sense level
- In- and output voltage and current alarms
The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature.
High start-up power
Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools.
When in ECO mode, the inverter will switch to standby when the load decreases below a preset value. Once in standby the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.
A remote on/off switch can be connected to a two pole connector, or between battery plus and the left hand contact of the two pole connector.
Please see manual for a description.
Available with different output sockets
|Cont. power at 25°C||250VA||375VA||500VA|
|Cont. power at 25°C/40°C||200W/175W||300W/260W||400W/350W|
|Output AC voltage/ frequency (adjustable)||230VAC ±3%, 50Hz or 60Hz ±0,1%|
|Input voltage range||9,2V-17V / 18,4V-34V / 36,8V-62V|
|DC low shut down (adjustable)||9,3V / 18,6V / 37,2V
Dynamic cut-off, see
|DC low restart and alarm (adjustable)||10,9V / 21,8V / 43,6V|
|Battery charged detect (adjustable)||14V / 28V / 56V|
|Max. efficiency||87% / 88% / 88%||89% / 89% / 90%||90% / 90% / 91%|
|Zero-load power||4,2W/ 5,2W / 7,9W||5,6W / 6,1W / 8,5W||6W / 6,5W / 9W|
|Default zero-load power in ECO mode (default rety interval: 2.5s ,adjustable)||0,8W / 1,3W / 2,5W||0,9W / 1,4W / 2,6W||1W / 1,5W / 3W|
|Protection||Protection key: output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, DC ripple too high|
|Operating temperature range||-40°C ÷ +65°C (derate 1,25% per °C above 25°C)|
|Material [&] Colour||Steel chassis and plastic cober (blue Ral 5012)|
|Maximum cable cross-section||10mm2 / AWG8|
|Standard AC outlets||Schuko (CEE 7/4), IEC-320 (male plug icluded), UK (BS 1363), AU/NZ (AS/NZS 3112)|
|Normy||EN/IEC60335-1, EN/IEC62109-1, EN55014-1, EN55014-2, IEC61000-6-1, IEC61000-6-3, 3004/104/EC, EN50498|
