Manufacturer: ZIEHL

STWA2AH - Electronic Current Transducer - S225580

  • S225580
  • Product Type IP00 motor, IP20 electronics
  • Execution Die-cast aluminum
  • Additional information PA plastic, black painted sheet metal
  • Output function Analog outputs 0/4-20 mA, 0-10 V
  • Measured value Insert made of aluminum sheet, sprayed with PP plastic

The STWA2 AH is a current-transducer for AC currents 0...20/100 A. With the STWA 2 AH the value of a current can be evaluated very economically and space-saving. The output-signal 4...20 mA can be evaluated or displayed with components with analog inputs, e.g. PLCs or ZIEHL digital displays type MINIPAN ®.

Overview of Functions

  • current-proportional analog output DC 4...20 mA according to AC-measuring range
  • measuring range (20/100 A) can be changed with bridge
  • insulated analog output
  • supply DC 9-30 V (via 4-20 mA-loop)
  • electrical connection via screwless pluggable terminals
  • DIN-rail-mount or with screws
  • plug-in current transformer (Ø 11 mm)
