Window screen shielding - Introduction

8 WINDOW SHIELDING

8.1 INTRODUCTION

DACPOL, in cooperation with OPTICAL FILTERS, offers complete window shielding solutions. Viz-Bond® bonding technology allows for excellent window transparency without air bubbles, impurities, filings, or dust. Viz-Bond® technology cures the material in the wavelength range of 390-500 nm, and therefore can be cured by a polarizer and materials containing UV inhibitors.



This technology complies with MIL-STD-810g / ASTM G151 standards - solar chamber. Mechanical resistance tests of the final window were carried out in accordance with the MIL-STD - 3122 standard (1" steel ball dropped from a 20-25" height), and vibration tests in accordance with MIL-STD-810F-514.5. Depending on the application and needs, various technologies are available for manufacturing complete windows and glass.

MANUFACTURER NAME TECHNOLOGY
Emiclare Micromesh Micromesh MM foil
- glass (standard)
- polycarbonate (optional)
Emiclare II Copper mesh (woven mesh) on:
- glass (old technology)
- polycarbonate
Emiclare ITO15 ITO 15 Ohms foil
ThermoClare ITO Heaters

Thickness Width x len
AR GLASS
1.1 mm 812x635 mm
1.3 mm 812x635 mm
1.6 mm 812x635 mm
2.3 mm 1270x812 mm
3.0 mm 1270x812 mm
4.0 mm 1605x950 mm
AG GLASS
1.1 mm 800x600 mm
1.6 mm 900x600 mm
1.9 mm 900x600 mm
3.0 mm 900x600 mm
4.0 mm 900x600 mm
ITO GLASS 4 Ohm
1.1 mm 850x550 mm
ITO GLASS 15 Ohm
1.1 mm 850x550 mm
PLAIN GLASS
1.1 mm 1600x620 mm
1.6 mm 1600x1070 mm
2.0 mm 1840x1220 mm
3.0 mm 2140x1220 mm
4.0 mm 2140x1320 mm

Thickness Width x len
PC AR POLYCARBONATE
0.50 mm 380x310 mm
3.00 mm 380x310 mm
PC AG POLYCARBONATE
0.50 mm 1220x700 mm
0.75 mm 1220x700 mm
1.00 mm 1150x975 mm
1.50 mm 1150x975 mm
2.0 mm 1150x975 mm
3.0 mm 1450x975 mm
4.0 mm 1450x975 mm
POLYCARBONATE PC PLAIN
1.00 mm 2050x1250 mm
1.50 mm 2050x1250 mm
2.0 mm 2050x1525 mm
3.00 mm 2440x1220 mm
4.00 mm 1500x1000 mm
PC AG POLYCARBONATE
0.50 mm 915x610 mm
0.75 mm 915x610 mm
2.00 mm 1200x1000 mm
3.00 mm 1500x1000 mm



WINDOW FINISH
Sputtered silver layer



Tinned copper tape



Direct Contact



Note: The window can be made of glass or polycarbonate with the option of a non-reflective coating or/and an anti-reflective coating.
