Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: M-SYSTEM

M2Dyh2 - Current loop power supply for HART signals

  • M2DYH2

M2DYH2 is a current loop power supply.


Features

  • Power supply for HART signals
  • Open circuit detection
  • It powers the 4… 20mA DC current loop
  • Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without the need to interfere with the wiring
  • Electrically isolates the output signal from the power input < / li>
  • Provides galvanic isolation
  • Short-circuit protection
  • Output power - 24 V DC
  • AC / DC power

    • Input: 4… 20mA
    Output: 4… 20mA


    Wire connection M3 screw terminals
    Separation Input / Output / Power
    Dielectric Strength DC: 2000V AC
    AC: 1500V AC
    Ranges selection None
    Double Exit None
    Power AC / DC < / td>
    Operating Temperature - 5 to + 55 ° C
    Mounting DIN rail
    Dimensions 23x76x124mm
