Manufacturer: SEIFERT mtm SYSTEM

Air conditioners - MINI type

Casing A Casing B Casing C Casing D
Casing E Casing F

Assembly methodTypeCooling power
[W]
L35L35*
Dimensions
[mm]
Nominal current and voltage
[A/V]
Air flow
conditioner/cabinet
[m3h]
Weight
[Kg]
Wall KG-4266 320 520x270x110 2,4/230 170/125 13,3 A
KG-4266 120 320 520x270x110 3,2/120 170/125 13,3 A
Wall KG-4268 400 520x320x110 1,5/230 200/125 14,2 B
KG-4268 120 400 520x320x110 3,2/120 200/125 14,2 B
KG-4267 400 340x520x110 1,5/230 200/125 14,8 C
KG-4267 120 400 340x520x110 3,2/120 200/125 16,8 C
KG-4269 430 600x320x110 1,5/230 200/125 16,0 D
KG-4269 120 430 600x320x110 3,2/120 200/125 16,0 D
Roof KG-4480 200 210x255x350 1,5/230 200/125 14,0 E
KG-4480 120 200 210x255x350 3,2/120 200/125 14,0 E
KG-4482 450 230x330x430 1,9/230 250/140 23,0 F
KG-4482 120 450 230x330x430 3,6/120 250/140 23,0 F

Cation
  *L35L35
    |  |____ external temperature
    |_______ cabinet temperature
