Manufacturer: FANDIS

D06A05HWHA00 DC axial fan 24V 2.88W

  • D06A05HWHA00
  • Air flow direction Exhaust through brackets
  • Dimensions 60 x 60 x 25 mm
  • Rated voltage 24
  • Housing material Plastik UL94-V0
  • Protection rating IP20
  • Input power 2,88
  • Speed 4500
  • Current draw 0,12
  • Air flow 40
  • Certificate CE; cURus; UKCA
  • Mounting method screws
  • Static Pressure 63
  • Noise Level 33.1
  • Voltage Input Min (V) 17
  • Fan type DC axial
  • Voltage range 21,6-26,4
  • Type of voltage DC
  • Motor protection Electronically secured
  • Insulation class A
  • Motor bearing Hypro bearing
  • Electrical hookup Wires
  • Storage temperature -40÷70 °C
  • Working temperature -10÷70 °C
