Calculation of E-Chain®-lengths and camber
  • Calculation of E-Chain®-lengths and camber

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: Igus

Selection of cable guides

If the fixed end of the E-Chain® is placed in the center of the travel, the chain length LK comes to half of the travel distance plus an extra K for the bending radius. The value K can always be gathered from the table in the catalog. The most cost-efficient solution is to always place the fixed end at the center of the travel, as less E-Chains® and, in the majority of cases, less cables are required.
