Photos are for informational purposes only. View product specification

Fast thyristor/ Fast diode

VISHAY (IR) ELECTRO INSULATED MODULES


FAST THYRISTOR / FAST THYRISTOR

Table. Electrical Data


Module TypeIT(AV)
[A]
URRM
[V]
IFSM
[A]
I2t
[A2t
[A]
I GT
[mA]
tq
[µs]
trr
[µs
duD/dt
[V/µs]
Rthjc
[°C/W]
Rthcs
[°C/W]
Screw Torque
[Nm]
Casing
IRKHF180-..H. IRKLF180-..H. 180 200-1200 7130 256000 200 18-25 2 400 0,125 0,025 4-6 MAGN-A-Pak
IRKHF200-..H. IRKLF200-..H. 200 200-1200 7600 290000 200 18-25 2 400 0,125 0,025 4-6

Code N M L P K J
tq 10 12 15 18 20 25
