HAX 500-S current transducer
HAX 500-S current transducer

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: LEM

HAX 500-S current transducer

  • HAX 500-S
  • Accuracy 1,00%
  • Rated Current [A] 500
  • Primary signal [AC / AC+DC / DC] AC+DC
  • Supply voltage [V] 15V DC
  • Mounting [THT / SMD / DIN / Panel / On primary rail] Panel
  • App Automation/Drives/Renewable energy/Power supplies/Welding machines
  • Output signal type [current/voltage] voltage
  • Minimum operating temperature [°C] -40
  • Maximum operating temperature [°C] 85
  • Frequency response (-3dB) [kHz] 25
  • Feedback loop [open / closed] // Eta technology open

HAX 500 … 2500-S Current Transducer

For electronic measurement of currents: direct, alternating, pulsed..., with galvanic isolation between primary and secondary circuits.

Features

  • Hall effect measurement
  • Insulated plastic housing compliant with UL 94-V0.

Advantages

  • Low insertion loss
  • Easy installation
  • Low power consumption
  • Compact size and space saving
  • One design for a wide range of nominal currents
  • High interference immunity External.

Applications

  • AC Adjustable Speed ​​Drives and Servo Motor Drives
  • Static Converters for DC Motor Drives
  • Battery-Powered Applications
  • Uninterruptible Power Supplies (UPS)
  • Switched Switched-Mode Power Supplies (SMPS)
  • Power Supplies for Welding Applications.
Series HAX
Measurements Current
Value Nominal 500 A
Measuring Range 1500 A
Secondary Nominal Signal Voltage
Secondary Nominal Signal Value Instantaneous 4 V
Primary Signal AC + DC
Supply Voltage External DC Bipolar
Supply Voltage Range ±15 V
Accuracy 1 %
Operating Temperature -40 °C / 85 °C
Technology Open-loop Hall Effect
Mounting Panel Mount
Applications Drives, Power Supplies, Renewable Energy Sources, Welding
Less
Read more
448.95 PLN
448.95 PLN Gross price / pcs.
365.00 PLN Net price / pc.
Tax included

Availability: Please be advised that this product is out of stock

You can place a pre-order, report your interest in the product by clicking the "Ask for availability" button.

Out of stock
