IT 60-S ULTRASTAB current transducer
IT 60-S ULTRASTAB current transducer

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: LEM

IT 60-S ULTRASTAB current transducer

  • IT 60-S ULTRASTAB
  • Accuracy 0,03%
  • Rated Current [A] 60
  • Primary signal [AC / AC+DC / DC] AC+DC
  • Supply voltage [V] 15V DC
  • Mounting [THT / SMD / DIN / Panel / On primary rail] Panel
  • App Automation/Renewable Energy
  • Output signal type [current/voltage] current
  • Minimum operating temperature [°C] 10
  • Maximum operating temperature [°C] 50
  • Frequency response (-3dB) [kHz] 800
  • Feedback loop [open / closed] // Eta technology closed

Applications:

  • Feedback element in high-performance gradient amplifiers for MRI
  • Feedback element in high-precision and stable power supplies
  • Calibration unit
  • Energy measurement
  • Medical equipment

Technical data:

Measured quantity Current
Rated current 60A
Measuring range ±60A
Output signal Current, ±100mA
Primary signal AC+DC
Power supply 15V DC
Accuracy 0.02725%
Operating Temperature 10°C…50°C
Technology Fluxgate IT Closed Loop
Mounting Panel
