LA 25-P current transducer
LA 25-P current transducer

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: LEM

LA 25-P current transducer

  • LA 25-P
  • Accuracy 1.25
  • Rated Current [A] 25
  • Primary signal [AC / AC+DC / DC] AC+DC
  • Supply voltage [V] ±12…15
  • Mounting [THT / SMD / DIN / Panel / On primary rail] THT
  • App Drives/Power Supplies/Renewable Energy/Welding
  • Output signal type [current/voltage] voltage
  • Minimum operating temperature [°C] -25
  • Maximum operating temperature [°C] 85
  • Frequency response (-3dB) [kHz] 200
  • Feedback loop [open / closed] // Eta technology closed

LA 25-P Current Transducer

For electronic measurement of currents: direct, alternating, pulsed..., with galvanic isolation between primary and secondary circuits.

Functions

  • Closed loop (compensated) using the Hall effect
  • Insulated plastic housing compliant with UL 94-V0.

Advantages

  • Excellent measurement precision
  • Very good linearity
  • Low temperature drift
  • Optimal response time
  • Wide frequency band
  • No insertion losses
  • High interference immunity External
  • Current Overload Resistance

Applications

  • AC Adjustable Speed ​​Drives and Servo Motor Drives
  • Static Converters for DC Motor Drives
  • Battery-Powered Applications
  • Uninterruptible Power Supplies (UPS)
  • Switched Switched-Mode Power Supplies (SMPS)
  • Power Supplies for Welding Applications
Series LA55
Measurements Current
Nominal Value 25 A
Measuring Range 55 A
Secondary Nominal Signal Current
Secondary Nominal Signal Value Instantaneous 25 mA
Signal Primary AC + DC
Supply Voltage External DC Bipolar
Supply Voltage Range 12 - 15 V
Accuracy 1.25 %
Operating Temperature -25 °C / 85 °C
Technology Hall Effect in a Closed Circuit loop
Assembly PCB
Applications Drives, Power Supplies, Renewable Energy Sources, Welding
Less
Read more
180.81 PLN
180.81 PLN Gross price / pcs.
147.00 PLN Net price / pc.
Tax included

Availability: Please be advised that this product is out of stock

You can place a pre-order, report your interest in the product by clicking the "Ask for availability" button.

Out of stock
