PCM 30-P current transducer
PCM 30-P current transducer

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: LEM

PCM 30-P current transducer

  • PCM 30-P
  • Accuracy 1,00%
  • Rated Current [A] 30
  • Primary signal [AC / AC+DC / DC] AC+DC
  • Supply voltage [V] 24V DC
  • Mounting [THT / SMD / DIN / Panel / On primary rail] Panel
  • App Automation/Power Supplies/Automotive Batteries
  • Output signal type [current/voltage] current
  • Minimum operating temperature [°C] -25
  • Maximum operating temperature [°C] 55
  • Frequency response (-3dB) [kHz] 1
  • Feedback loop [open / closed] // Eta technology closed

Applications:

  • Point status monitoring
  • Traffic lights
  • Battery-powered applications
  • Uninterruptible power supplies (UPS)

Technical data:

Rated current 30A
Measuring range ±60A
Output signal Current, 4…20mA
Primary Signal AC+DC
Power Supply 24V DC
Accuracy 1%
Operating Temperature -25°C…55°C
Technology Closed feedback loop, the phenomenon Halla
Mounting Panel
