Single-phase rectifier bridges

Housing type3 x 3 x 1.8 (So)4.7 x 3.9 x 2.4 (So)8.5 x 6.6 x 3.28.5 x 6.6 x 3.2
Single-phase bridgesVoltage
VRRM
[V]		;
Current0,5 [A]0,8 [A]1 [A]1 [A]
Standard40MYS20S20B20SB20D
80MYS40S40B40SB40D
160MYS80S80B80SB80D
250MYSI 25S125B125SB125D
600MYS250S250B250SB250D
800S380B380SB380D
1000S500B500SB500D
Fast40B20FSB20FD
80B40FSB40FD
160B80FSB80FD
250B125FSB125FD
600B250FSB250FD
800B380FSB380FD

Housing type19 x 4.4 x 10Ø 8.5 x 5.132 x 5.6 x 17
Single-phase bridgesVoltage
V RRM
[V]
Current2.3 [A] / 1.5 [A]2 [A]3.2 [A] / 2.2 [A]3.7 [A] / 2.2 [A]5 [A] / 3 [A]5 [A] / 3.3 [A]7 [A] / 4 [A]
Standard80B40C2300-1500B40RB40C3200-2200B40C3700-2200B40C5000-3000B40C5000-3300B40C7000-4000
160B80C2300-1500B80RB80C3200-2200B80C3700-2200B80C5000-3000B80C5000-3300B80C7000-4000
250B125C2300-1500B125RB125C3200-2200B125C3700-2200B125C5000-3000B125C5000-3300B125C7000-4000
600B250C2300-1500B250RB250C3200-2200B250C3700-2200B250C5000-3000B250C5000-3300B250C7000-4000
800B380C2300-1500B380RB380C3200-2200B380C3700-2200B380C5000-3000B380C5000-3300B380C7000-4000
1000B500C2300-1500B500RB500C3200-2200B500C3700-2200B500C5000-3000B500C5000-3300B500C7000-4000

Case type19 x 4.4 x 1032 x 5.6 x 17
Single-phase bridgesVoltage
V RRM
[V]
Current4 [A]10 [A]15 [A]20 [A]25 [A]
Standard50GBS4AGBI10AGBI15AGBI20AGBI25A
100GBS4BGBI10BGBI15BGBI20BGBI25B
200GBS4DGBI10DGBI15DGBI20DGBI25D
400GBS4GGBI10GGBI15GGBI20GGBI25G
600GBS4JGBI10JGBI15JGBI20JGBI25J
800GBS4KGBI10KGBI15KGBI20KGBI25K
1000GBS4MGBI10MGBI15MGBI20MGBI20MGBI25M

Case type20.8 x 3.3 x 1823.5 x 19.3 x 5.7
Single-phase bridgesVoltage
V RRM
[V]
Current4 [A]6 [A]8 [A]12 [A]4 [A]6 [A]8 [A]12 [A]
Standard50GBU4AGBU6AGBU8AGBU12AKBU4AKBU6AKBU8AKBU12A
100GBU4BGBU6BGBU8BGBU12BKBU4BKBU6BKBU8BKBU12B
200GBU4DGBU6DGBU8DGBU12DKBU4DKBU6DKBU8DKBU12D
400GBU4GGBU6GGBU8GGBU12GKBU4GKBU6GKBU8GKBU12G
600GBU4JGBU6JGBU8JGBU12JKBU4JKBU6JKBU8JKBU12J
800GBU4KGBU6KGBU8KGBU12KKBU4KKBU6KKBU8KKBU12K
1000GBU4MGBU6MGBU8MGBU12MKBU4MKBU6MKBU8MKBU12M

Case type28.6 x 28.6 x 7.328.6 x 28.6 x 10
Single-phase bridgesVoltage
V RRM
[V]
Current10 [A]15 [A]25 [A]35 [A]50 [A]25 [A]35 [A]
Standard50KBPC1000KBPC1500KBPC2500KBPC3500KBPC5000 *)KBPC2500 IKBPC3500 I
100KBPC1001KBPC1501KBPC2501KBPC3501KBPC5001 *)KBPC2501 IKBPC3501 I
200KBPC1002KBPC1502KBPC2502KBPC3502KBPC5002 *)KBPC2502 IKBPC3502 I
400KBPC1004KBPC1504KBPC2504KBPC3504KBPC5004 *)KBPC2504 IKBPC3504 I
600KBPC1006KBPC1506KBPC2506KBPC3506KBPC5006 *)KBPC2506 IKBPC3506 I
800KBPC1008KBPC1508KBPC2508KBPC3508KBPC5008 *)KBPC2508 IKBPC3508 I
1000KBPC1010KBPC1510KBPC2510KBPC3510KBPC5010 *)KBPC2510 IKBPC3510 I
1200KBPC1012KBPC1512KBPC2512KBPC3512
1400KBPC1014KBPC1514KBPC2514KBPC3514*) only
1600KBPC1016KB'C1516KBPC2516type F

Case type15.2 x 15.2 x 6.319 x 19 x 6.815.1 x 15.1 x 5
Single-phase bridgesVoltage
V RRM
[V]
Current6 [A]8 [A]10 [A]10 [A]
Standard50KBPC600KBPC800PB1000PB1000S
100KBPC601KBPC801PB1001PB1001S
200KBPC602KBPC802PB1002PB1002S
400KBPC604KBPC804PB1004PB1004S
600KBPC606KBPC806PB1006PB1006S
800KBPC608KBPC808PB1008PB1008S
1000KBPC610KBPC810PB1010PB1010S
