OLI95 Al/Cu 1x25-95mm² High-strength device clamp MAJ1095S10
OLI95 Al/Cu 1x25-95mm² High-strength device clamp MAJ1095S10

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: MOREK

OLI95 Al/Cu 1x25-95mm² High-strength device clamp MAJ1095S10

  • MAJ1095S10
  • Width (mm) 40
  • Depth (mm) 87
  • Rated voltage 690
  • Colour Inne
  • Height (mm) 60
  • Mounting method Inne
  • Rated Current [A] 320
  • Cross-section of the fine-wire connecting cable without cable end sleeve [mm²] 25..95
  • Cross-section of fine-strand connecting cable with end sleeve [mm²] 25..95
  • Cross-section of connecting wire, solid wire [mm²] NA
  • Cross-section of connectable multi-core cable [mm²] 25..95
  • Type of electrical connection Screw connection
  • Number of levels 1
  • Number of clamp positions per level 1
  • Insulating body material Thermoplastic material
  • Flammability class of the insulating material according to UL94 V2
  • Explosion-tested version "Ex e" NO
  • Closing plate required NO
  • Internally connected steps Yes
  • Working temperature ..80
