Manufacturer: ZIEHL

AS60-5 - Current Transformer for AC-Current - S225174

  • S225174
  • Product Type IP00 motor, IP20 electronics
  • Execution Die-cast aluminum
  • Additional information PA plastic, black painted sheet metal
  • Measured value Insert made of aluminum sheet, sprayed with PP plastic

For currents >5A current monitors require a current transformer with secondary 1 or 5 A and a rated capacity of 1.5 VA. The primary rated current must be appropriate to the max. expected current(fuse). Tube ore wound current transformers can be used.
For primary rated currents of 60 to 500 A we recommend using AS tube current transformers, suitable for the Cu-rail of 30 x 10 mm or 2 x 20 x 10 mm or round conductor of 28 mm. The transformers have Class 1 accuracy and a voltage resistance of up to 800 V. When ordering, please indicate desired primary and secondary rated current.
