Xer1032 - Reflectual safety circuit breakers for EX zone

Explosion-proof stainless steel housing for the most demanding applications with cable spans up to 200m.

For machine builders looking for greater flexibility when installing a cable pull switch along or around heavy machinery in potentially explosive environments, the XER1032 offers a center-mount option and an explosion-proof housing. Installation and routine maintenance are easy thanks to operation indicators and voltage indicators. With a cantilever span of up to 200 m and a rugged, vibration-resistant housing, the XER1032 is ideal for keeping workers safe in industrial applications or harsh environments.

Features

• Rugged Housing - The die-cast housing and stainless steel eye nut make the XER1032 suitable for demanding industrial applications.
• The IP67 (NEMA 6) enclosure makes the XER1032 washdown-proof.
• Integrated Emergency Stop - The optional emergency stop button provides an emergency stop at the end of the line and is field serviceable.
• A tension indicator simplifies system setup and maintains rope tension.
• 1 N/C + 1 N/A contact arrangement. O
• Vibration Resistant - Snap-in switch contacts prevent nuisance tripping due to vibration.
• Long Life - The XER1032 switch is designed for a minimum of one million actuations.
• Reset Button - The blue reset button must be pressed to return to the "machine run" state after the switch is activated by a stretched or slack rope.
• Rubber bellows contain a UV inhibitor, making the switches suitable for outdoor applications.
