Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: B&B Electronics

Serial RS232 port servers - ETHERNET - panel - ESP411/ESP412/ESP414

The ESP41_ series serial servers are available with 1, 2, and 4 RS-232/422/485 serial ports. This device allows you to remotely monitor a serial connection. This server offers 10/100 Mbps throughput using TCP/IP or UDP/IP protocols. The supplied VLinx software allows for easy device configuration.

ESP411/ESP412/ESP414 can operate in various modes:
• virtual COM port
• TCP/IP server/client
• UDP/IP server/client

Specifications:
• RS-232, RS-422, RS-485 2-wire or 4-wire
• connection resumption after power or connection loss
• Ethernet port: 10/100 Mbps with auto-detection, IEEE 802.3u standard
• supports Ethernet protocols: TCP, UDP, IP, ARP, ICMP, HTTP, Telnet, DHCP
• high throughput from 110 bps to 230.4 kbps
• connector DB9 serial port (Terminal Block in ESP411)
• RJ45 Ethernet connector
• Operating temperature: 0°C to +55°C
• 12VDC power supply (power supply included),
• Panel or DIN rail mounting,
• 5-year warranty.
