Manufacturer: ZIEHL

MS220KA-AC220-240V-1U - PTC Thermistor Relay - T228116

  • T228116
  • Product Type IP54 motor, IP20 electronics
  • Supply voltage AC 220-240 V
  • Execution Motor IP44, electronics IP20 / depending on mounting and position
  • Additional information Black painted aluminum sheet
  • Certificate UL/CSA, ATEX, UKCA, EU-Deklaracja Zgodności
  • Output function Outputs/Relays
  • Measured value Electronic protection against reverse polarity and locked rotor.

PTC-relay for the application as a protection device against inadmissible heating up at electrical equipment in areas with explosive gases (zones 1 and 2) and areas with combustible dust (21 and 22), e.g. for direct temperature-monitoring of explosion-proof motors EEx e and EEx d. Vertically arranged terminals. Each terminal remains accessible even if all others are already occupied.

Changes from T222451 to T228114; T222455 -> T228115; T222445 to T228116: Version with spring terminals RoHS/REACH compliant
Further information can be found in our customer information: "New terminals for K-type devices"

Features

  • ATEX directive 2014/34/EU
  • SIL 1 according to IEC 61508
  • PL c according to ISO 13849
  • 1 PTC-resistor (thermistor) set, each 3 or 6 PTC-sensors
  • short-circuit monitoring of sensor-circuit
  • output-relay with 1 or 2 change-over contacts (co)
  • 2 LEDs for ON and ALARM
  • K-housing, vertically arranged terminals housing 22.5 mm wide
  • assembly on DIN-rail or with 2 screws M4 (option)
  • UL Recognized Component
  • Option: other supply voltages
