AK 50 B420L current transducer
AK 50 B420L current transducer

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: LEM

AK 50 B420L current transducer

  • AK 50 B420L
  • Accuracy 1,00%
  • Rated Current [A] 10, 20, 50
  • Primary signal [AC / AC+DC / DC] AC
  • Supply voltage [V] Loop powered
  • Mounting [THT / SMD / DIN / Panel / On primary rail] Panel/DIN
  • App Automation/Drives
  • Output signal type [current/voltage] current
  • Minimum operating temperature [°C] -20
  • Maximum operating temperature [°C] 50
  • Frequency response (-3dB) [kHz] 0,1
  • Feedback loop [open / closed] // Eta technology Current transformer

Applications

  • Automation Systems
  • Analog current reading for remote monitoring (e.g., engine)
  • Data Loggers
  • The transducer does not require a power supply, so it does not drain the data logger's battery.
  • Panel Meters
  • Simple connection displays energy consumption.

Technical Data

Parameter Value
Measured Quantity Current
Rated Current 10, 20, 50A
Measuring Range 50A
Output Signal Current, DC RMS 4-20mA
Signal Primary AC
Power Supply Loop-based
Accuracy 1%
Operating Temperature -20°C…50°C
Technology Current Transformer
Mounting On Busbar DIN
Panel -
