Slotted light barrier (infrared radiation) - PBI-40-40 to PBI-60-75 type
  • Slotted light barrier (infrared radiation) - PBI-40-40 to PBI-60-75 type

Photos are for informational purposes only. View product specification

Manufacturer: Vester

Slotted light barrier (infrared radiation) - PBI-40-40 to PBI-60-75 type

Slotted light barrier (infrared radiation) - PBI-40-40 to PBI-60-75 type
Specifications

• Circuit constant light trigger
• Voltage 12...24V
• Current consumption: 50...200mA
• Operation: dynamic/static
• Sensitivity static/dynamic adjustable by 270° poti
• Output with LED PNP
• Function bright-dark switch
• Output current 500mA,
• Pulse length 10ms, adjustable (1-100 ms.) 10 ms
• Frequency depending on pulse length, max. 1 kHz
• Operating temperature 0...60°C
• EMC: IEC 801.... CE
• Type of protection IP65

Accuracy:
  Ball-Ø (dynamic) 1,0 mm
  Ball-Ø (static) 2,0 mm


Dimensions [mm]

Catalogue numberLight barrierABB1Terminal - 3 pole M8 socket
PBI-40-40/3-P 8344-00000-3002 40 40 35
PBI-50-75/3-P 8357-00000-3002 50 75 69
PBI-60-75/3-P 8367-00000-3002 60 75 69
