Analog time relay ATP4

• 48 x 48mm sized.
• Triggering whit supply voltage.
• Triggering output (OUT1).
• Contact output for timing function (OUT2).
• 6 Different timing modes for OUT2 (A, B, C, D, E, F).
• 6 Different timing unit selections for OUT2 (S,10S, M, 10M, H, 10H).
• Suitable for 8/11 pin octal or 7/10 screw-terminal connection.
• Start, reset and gate inputs for 10 pins screw-terminal or 11 pin octal connector.
• CE marked according to European Norms

Connection diagram
