Product overview E cores
  • Product overview E cores

Photos are for informational purposes only. View product specification

Product overview E cores

Product overview E cores

Core typeVe
[mm3]
Ae
[mm2]
Mass
[g]
Datasheets

E5.3/2.7/2

33.3 2.66 0.08 E53272.pdf

E6.3/2.9/2

40.6 3.30 0.12 E63292.pdf

E8.8/4.1/2

78.0 5.00 0.25 E88412.pdf

E13/6/3

281 10.1 0.7 E1363.pdf

E13/6/6

559 20.2 1.4 E1366.pdf

E13/7/4

369 12.4 0.9 E1374.pdf

E16/8/5

750 20.1 2.0 E1685.pdf

E16/12/5

1070 19.4 2.6 E16125.pdf

E19/8/5

900 22.6 2.3 E1985.pdf

E19/8/9

1650 41.3 4.0 E1989.pdf

E20/10/5

1340 31.2 4.0 E20105.pdf

E20/10/6

1490 32.0 3.7 E20106.pdf

E20/14/5

1513 24.0 4.2 E20145.pdf

E25/10/6

1930 37.0 4.8 E25106.pdf

E25/13/7

2990 52.0 8.0 E25137.pdf

E25/13/11

4500 78.4 11 E251311.pdf

E30/15/7

4000 60.0 11 E30157.pdf

E31/13/9

5150 83.2 13 E31139.pdf

E32/16/9

6180 83.0 16 E32169.pdf

E34/14/9

5590 80.7 14 E34149.pdf

E35/18/10

8070 100 15 E351810.pdf

E36/21/12

12160 126 31 E362112.pdf

E41/17/12

11500 149 30 E411712.pdf

E42/21/15

17300 178 44 E422115.pdf

E42/21/20

22700 233 56 E422120.pdf

E42/33/20

34200 236 82 E423320.pdf

E47/20/16

20800 234 53 E472016.pdf

E55/28/21

44000 353 108 E552821.pdf

E55/28/25

52000 420 130 E552825.pdf

E56/24/19

36000 337 90 E562419.pdf

E65/32/27

79000 540 205 E653227.pdf

E71/33/32

102000 683 260 E713332.pdf

E80/38/20

72300 392 180 E803820.pdf

E100/60/28

202000 738 493 E1006028.pdf
