HAT 1200-S current transducer
HAT 1200-S current transducer

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: LEM

HAT 1200-S current transducer

  • HAT 1200-S
  • Accuracy 1,00%
  • Rated Current [A] 1200
  • Primary signal [AC / AC+DC / DC] AC+DC
  • Supply voltage [V] 15V DC
  • Mounting [THT / SMD / DIN / Panel / On primary rail] Panel
  • App Automation/Drives/Renewable energy/Power supplies/Welding machines
  • Output signal type [current/voltage] voltage
  • Minimum operating temperature [°C] -40
  • Maximum operating temperature [°C] 105
  • Frequency response (-3dB) [kHz] 25
  • Feedback loop [open / closed] // Eta technology open

Applications:

  • DC motor drives
  • Switched-mode power supplies (SMPS)
  • Variable speed AC drives
  • Uninterruptible power supplies (UPS)
  • Battery-powered applications
  • Power supplies for welding applications

Technical data:

Measured quantity Current
Rated current 1200A
Measuring range ±2500A
Output signal Voltage, ±4V
Signal Primary AC+DC
Power Supply 15V
Accuracy 1%
Operating Temperature -40°C…105°C
Technology Open Loop, Hall Effect
Mounting Panel
